【三灯uv固化机】用于工艺品涂漆后干燥SK-304-300D

品牌：SunKun(三昆)

型号：SK-304-300D

订购：不限数量

价格：面议

⒈订购热线：13823369867(李先生) 1753480168

⒉业务咨询：13913507139(黄永贵) 2851085006



⒈市场部：13510246266(黄总经理) 289604232

1、UV灯功率:4.0kw*3支(卤素灯)
2、UV灯总长:420mm、弧长:300mm
3、UV波段主波峰:365nm、380nm
4、UV灯累时器配置
5、强弱光强调节:50%、100%
6、钣金灯箱安装光学反射器和光学滤光镜片
7、采用上、下排风系统
8、输送材料:不锈钢网带
9、输送宽度:300mm
10、输送速度:0~5m/min
11、入口高度:200mm
12、电源:380VAC 50HZ

1, UV lamp power: 4.0kw * 3 (halogen)
2, the total length of the UV lamp: 420mm, arc length: 300mm
3, UV band main peak: 365nm, 380nm
4, UV light timer configuration
5, strong and weak light intensity adjustment: 50%, 100%
6, sheet metal light box installed optical reflector and optical filter lens
7, using the upper and lower exhaust system
8, conveying materials: stainless steel mesh belt
9, conveying width: 300mm
10, conveying speed: 0~5m/min
11, the entrance height: 200mm
12, power: 380VAC 50HZ

1.配置3套UV光源系统，根据生产需要开启灯管数量。
2.铁氟龙输送网带，精工制作，运行平稳，无噪音。
3.调速电机及调速器，输送带无级调速可视生产情况调速输送速度。
4.聚光型设计，进口高聚光反光灯罩，瞬 时干燥，速度特快。
5.UV灯罩的光照高度可调整。
6.UV灯管的工作电流可通过外示表针显示，有效掌握UV系统的工作状态。
7.配备精巧的散热系统，防止工作腔室的温度过高，同时有效保护生产工作环境.

1. Configure 3 sets of UV light source system, and turn on the number of lamps according to production needs.
2. Teflon conveyor belt, made by precision, running smoothly and without noise.
3. Speed regulating motor and governor, conveyor belt stepless speed regulation can be adjusted according to production conditions.
4. Concentrating design, imported high-concentration reflector, instant drying, fast speed.
5. The illumination height of the UV lampshade can be adjusted.
6. The working current of the UV lamp can be displayed through the external indicator pin to effectively grasp the working state of the UV system.
7. Equipped with a sophisticated cooling system to prevent the temperature of the working chamber from being too high, and effectively protect the production environment.
